[arm-allstar] RX Audio only heard when Flashing Red LED is in ON State

[Joshua Hatton]

Hello Once Again, David
Thanks for your reply. I want to say that it does.  I will check and follow
up.

Let me share this: another user sent direct message a moment ago, saying
that they "found a documentation error on pinouts"... See the attached
pic.

I'm just using the controller alone; it appears they are using the RLS1000
board and an older brother CAT controller.

This is most interesting.


On Sun, Jul 12, 2020, 15:00 David McGough <kb4fxc at inttek.net> wrote:

>
> Does the RED TX LED behave normally (meaning "on" all the time when TX is
> asserted, "off" when TX not asserted), when unplugged from the controller?
>
> If is does, I expect the CAT250 has an issue with its COR pin not
> "floating" high and requiring active pull-down to enable.
>
>
> 73, David KB4FXC
>
>
>
> On Sun, 12 Jul 2020, "Joshua Hatton via ARM-allstar" wrote:
>
> > I am attempting to interface a Pi w/ Allstar to a CAT250 Controller.
> > I am running into an issue I've never experienced before.
> >
> > I appear to have success, in the aspect of "operation"... I am able to
> > send commands to HamVoIP over the controller audio, and able to hear
> > them, however, the audio received from the Pi/USB Interface is only
> > heard when the Flashing Red LED of the Interface is in the ON state
> > (It's not a steady light).  Very odd. There is a measured voltage on
> > that line as well, as the Red LED maintains a slight dim glow.
> > Thinking something was wrong with my Masters Comm. RA35 Interface, I
> > dug out an old URI Interface... It's doing the same thing exactly.
> > Something is definitely circumstantial with the controller.  Perhaps I
> > need to do a Pull-up/Pull-Down on **both** the PTT and COR Lines under
> > the circumstances?
> > That is pulling one to Pi USB Voltage and the other to controller PSU
> > voltage?  Just thinking out loud on that.  Wiring made as written
> > below.
> >
> > Pi USB Int.  < ---- >  CAT250 Link Port
> > ---------------------------------------------------------------
> >      PTT   < ---------------- >   COR
> >      COR  < ---------------- >   PTT
> >      RXA   < ----------------- >  TXA
> >      TXA   < ----------------- >  RXA
> >      GND  < ----------------- >  GND
> >
> > THanks for any guidance.
> > Josh W4ZZK
> > _______________________________________________
> >
> > ARM-allstar mailing list
> > ARM-allstar at hamvoip.org
> > http://lists.hamvoip.org/cgi-bin/mailman/listinfo/arm-allstar
> >
> > Visit the BBB and RPi2/3/4 web page - http://hamvoip.org
> >
>
>
